Name: SWC515-A SS 50t Weigh Module - Stainless Steel Load Cell for Tank & Silo Weighing Systems
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Weegmodule SWC515-A SS 50t
Availability: InStock

Thuis Producten

SWC515-A SS 50t Weigh Module - Stainless Steel Load Cell for Tank & Silo Weighing Systems

Productdetails:

Plaats van herkomst:	China
Merknaam:	Mettler Toledo
Modelnummer:	Weegmodule SWC515-A SS 50t

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	1 SET
Prijs:	Onderhandelbaar
Verpakking Details:	Kartonnen doos
Levertijd:	10-30 dagen
Levering vermogen:	2000 Reeks per maand

Contact

Gedetailleerde productomschrijving

Producten:	Mettler Toledo ladingcel	Maximale capaciteit:	50.000 kg (110.000 lb)
Materiaal:	Roestvrij staal V2A (AISI 304)	metrologie:	OIML C3, NTEP IIIL 10,000
Verzorgingscellen:	0782/GD, 13 m kabel	Nauwkeurigheid:	standaard
Beschermingscategorie:	IP68/69k	Omgeving / Materiaal:	Wasbaar / roestvrij staal
Gevaarlijke goedkeuring:	ATEX, FM	Criticaliteit:	standaard
Markeren:	stainless steel weigh module , 50t load cell for tanks , silo weighing system load cell

SWC515-A SS 50t Weigh Module - Stainless Steel Load Cell for Tank & Silo Weighing Systems

Product Overview

A compression weigh module designed for tank and silo weighing applications. When weight is applied, the top plate and base plate compress toward each other. This module can be directly attached to the ground, piers, or structural beams, making it ideal for large platform scales including truck and railroad track scales.

Key Features

Multi-Purpose Design: Suitable for static & dynamic tanks, hoppers, mixers, and conveyors with high accuracy stainless steel hermetic load cell
Enhanced Safety: Mechanical safety features including 360° self-checking, lift-off & down-stops protections with hazardous approvals
Easy Installation: SafeLock™ plates prevent damage during installation with integrated space for hydraulic jack
Durable Construction: Stainless steel V2A (AISI 304) material with IP68/IP69k protection rating

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	110,000 lb (50,000 kg)
Material	Stless Steel V2A (AISI 304)
Metrology	OIML C3, NTEP IIIL 10,000
Load Cell	0782/GD, 13 m cable
Accuracy	Standard
Protection Rating	IP68/69k
Environment/Material	Wash-down/Stainless Steel
Hazardous Approval	ATEX, FM
Criticality	Standard

Applications

Ideal for tank, hopper, and silo weighing applications with capacity ranges from 3 kg to 300 tons. Perfect for industrial environments requiring durable, high-capacity weighing solutions.
